This is the Arrma Kraton V5 6S BLX 2020 Spec Monster Truck RTR, Blue ARA8608V5T2

The Arrma Kraton 6S BLX RTR 1/8 4WD Brushless Monster Truck V5 is driven by an updated, 6S-capable power system and supported by a strengthened chassis design. The Kraton 6S BLX 4WD Speed Monster Truck is ready out of the box to reach incredible speeds for thrilling, all-terrain bashing.

ARRMA engineers have outfitted the KRATON 6S BLX 4WD with a brushless power system that now features the Spektrum Firma 150A Smart ESC and Firma 2050Kv brushless motor. The combination delivers incredible torque, acceleration and speed. Heavy-duty aluminum and steel chassis and transmission components take it all in its stride. For improved steering, ARRMA also includes a steel gear Spektrum S652 Digital Servo which is 32% stronger and 5% faster than the previous version's ADS-15M servo. Add your favorite 4S or 6S LiPo battery and watch this monster truck smash your speed expectations — up to 60+ MPH in optimum conditions with a 6S LiPo battery and the included optional speed pinion gear.

The ready-to-run package now also includes a 3-channel Spektrum SLT3 radio and Spektrum SR315 dual protocol receiver. Perfect for long hours of fatigue-free bashing, the transmitter's ergonomic design features a foam steering wheel for precise fingertip control and an improved hand grip and trigger feel. If you're a new driver, you'll be able to set throttle limits at 50% or 75% until you're ready to use the full speed potential. The SLT3 is compatible with Tactic SLT receivers to run other RTR vehicles you may own, and includes a third channel to control optional features such as lights and winches on models that have them. Because the SR315 receiver can use SLT and DSMR protocols, you can easily upgrade to a Spektrum DSMR transmitter later — then, download the free Spektrum Dashboard app for your mobile device and take full advantage of the Smart telemetry capabilities already present in the Firma electronics. You'll be able to receive real-time updates of ESC temperature, receiver (BEC) voltage, drive pack voltage and motor RPM.

Features:

Ready-to-Run
60+ MPH (97 km/h) speeds achievable in optimum conditions using a 6S LiPo battery and the include optional speed pinion gear
Spektrum™ SLT3™ 2.4GHz 3-Channel Radio
Spektrum™ SR315 Dual Protocol 3-Channel Receiver
Spektrum™ S652 Digital Servo
Spektrum™ Firma™ 150A Smart ESC
Spektrum™ Firma™ 4074 2050Kv Brushless Motor
Safe-D pinion gears
EXB front brace compatible top plate
Stronger chassis design
Heavy-duty arms front and rear
Updated rear shock tower geometry
Large volume waterproof* receiver box
Anodized aluminum chassis
Strong composite chassis side pods
Center body support and brace for maximum durability
High downforce wing
Oil-filled adjustable shocks
Black-anodized aluminum front and rear shock towers
Durable steel driveshafts throughout
Heavy-duty drivetrain
All-metal diff outdrives and gearbox internals
Never-loose red aluminum servo saver
Never-pop ball ends
4-Bolt center diff removal
Easy-access sliding motor mount for quick motor removal
Multi-split spoke wheels
Durable wheel hubs for increased strength
Hub nut O-rings
Multi-terrain dBoots® COPPERHEAD 2™ tires
Detailed decals
Body print style in red/black or blue/black
IC5® connectors (EC5™ compatible)
2-year limited warranty (see manual for details)

*NOTE: For details on waterproof standards, please refer to the product instruction manual

Specifications:

Approximate Assembly Time: No assembly required

Ball Bearings: Full set

Battery: Sold Separately

Body: Painted, decaled and trimmed

Brakes: User programmable

Charger: Sold Separately

Chassis: 0.12" (3mm) 6061-T6 aluminum

Completion Level: Ready-To-Run

Differential: 3-gear

Drivetrain: 4WD

Drive Type: Forward/Brake/Reverse

Final Drive Ratio: 17.92

Front Shock Spring Rate: 6.2lbs/in (1.09N/mm)

Front Track: 18.15" (461mm)

Power Type: Electric

Gear Pitch: 1.0MOD

Ground Clearance: 1.85" (47mm)

Inner Tire / Outer Wheel Diameter: 3.8 in

Internal Gear Ratio: 4.3

Motor Size: 4074

Motor Type: Brushless - Sensorless

Pinion: 12T

Product Height: 7.68" (195 mm)

Product Length: 23.39" (594 mm)

Product Weight: 10.67lb (4.85kg)

Product Width: 18.15" (461 mm)

Radio: Included

Rear Shock Spring Rate: 5.0lbs/in (0.87N/mm)

Rear Track: 18.15" (461mm)

Receiver: Included

Scale: 1/8

Servos: Included

Shock Type: Aluminum body oil-filled adjustable

Speed Control: Included

Spur Gear: 50T

Suspension: Independent

Tire Tread: dBoots COPPERHEAD 2

Tire Type: Multi-terrain

Vehicle Type: Monster Truck

Water-Resistant: Yes

Wheelbase: 14.84" (377mm)

Wheel Hex Size: 17mm

Wheel Type: Five split-spoke monster truck

Wheel Width: 3.3" (81.5mm)

Includes:

ARRMA® KRATON™ 6S BLX 1/8 Speed Monster Truck 4WD RTR
Spektrum™ Firma™ 150A Smart 4S/6S ESC (installed)
Spektrum ™ Firma ™ 4074 2050Kv Brushless Motor with ARRMA® Heatsink (installed)
Spektrum ™ S652 Metal-Geared Digital Servo (installed)
Spektrum ™ SR315 3-Channel Dual Protocol Receiver (installed)
Spektrum ™ SLT3™ 2.4GHz 3-Channel Radio

Needed to Complete:

4S or 6S LiPo Battery
LiPo Compatible Charger
LiPo Charging Bag
(4) AA Batteries
